Armstrong 2011 Stainless Steel Inverted Bucket Steam Trap C5324-7

The Armstrong 2011 Inverted Bucket Steam Trap is the star of Armstrong International's 2000 Series, designed for industrial steam systems to provide reliable condensate removal and steam retention. As an all-stainless steel inverted bucket steam trap, it combines energy efficiency, ease of installation, and long service life for heating, drying, and process control applications in high-pressure environments. If you are looking for a high-performance steam trap solution, the Armstrong 2011 is the ideal choice.

Product specifications and technical parameters

The Armstrong 2011 steam trap utilizes the advanced inverted bucket principle, which automatically opens and closes using the difference in density between condensate and steam, ensuring efficient drainage without steam leakage. Detailed specifications are listed below:

• Available types: 2011 (including 2011C variants).
• makings: All wetted parts are stainless steel, providing superior corrosion resistance and durability for harsh industrial environments.
• pipe connection: 1/2" or 3/4" (15-20 mm), supports 360° universal connectors for easy in-line installation.
• Maximum working pressure: 400 psig (28 barg) for high pressure steam systems.
• quantitative (science): Up to 880 lb/hr (400 kg/hr) for efficient handling of high-flow condensate.
• Size and Installation: Withdrawal length of approximately 50 mm, requires 635 mm of bolt mounting clearance; lightweight, compact design for space-constrained applications.
• durability: Resistant to freeze damage without additional protection; sealed, tamper-proof packaging ensures safety and reliability.

For more technical details, please refer to the official datasheet:Armstrong 2000 Series Inverted Bucket Steam Trap Data Sheet cap (a poem) 2011C Model SpecificationThe

Product Advantages

The Armstrong 2011 Stainless Steel Inverted Bucket Steam Trap excels in energy savings, ease of installation and maintenance costs:

• energy-saving and efficient: Based on the principle of density difference, condensate and air are quickly discharged, reducing steam loss and improving system efficiency. Significantly reduces energy consumption compared to conventional traps.
• Easy to install and replaceThe IS-2 connector or standard connector supports quick in-line replacement without interrupting piping operations. 360° swivel design accommodates a variety of mounting angles.
• Corrosion resistance and durability: All stainless steel construction resists chemical corrosion and high temperatures; freeze-resistant feature ensures reliable operation in cold environments.
• Compatible extensions: Can be integrated with the Armstrong Pop Drain drainage system, TrapAlert™ monitor and SteamEye™ remote steam monitoring to enhance intelligent management.
• economicsLightweight design reduces transportation costs; long life reduces replacement frequency for food processing, chemical, pharmaceutical, and HVAC systems.

These advantages make Armstrong 2011 the product of choice in steam management systems. View the Maintenance Guide:Armstrong Steam Trap Service GuideThe

application scenario

Armstrong 2011 Inverted Bucket Steam Traps are used in a wide variety of industrial scenarios including:

• Steam Heating SystemThe following are some examples: heat exchangers, dryers and cooking equipment to ensure efficient heat transfer.
• process control: Chemical plants, pharmaceutical plants and food processing lines, handling high pressure steam requirements.
• HVAC and Buildings: Steam supply system for commercial buildings providing reliable drainage.
• high pressure environment: 200 PSI maximum (for specific sub-models) operation for heavy industrial applications.

If your system requires a highly efficient steam trap, Armstrong 2011 can provide a customized solution. Refer to the application catalog:Armstrong Steam Trap RangeThe

Maintenance & Support

To ensure optimum performance of Armstrong 2011 steam traps, it is recommended that mechanisms and spare parts be checked regularly.Armstrong offers full service support, including replacement parts for specified trap models. When installing, allow sufficient clearance and follow safety regulations.

Get more support documentation:Armstrong International Steam Trap CatalogThe
