Spirax Sarco Spirax Sarco CSF16/CSF16T Stainless Steel Filters
¥1,500.00 – ¥8,900.00
Brand authorization
- Rapid response service
- Professional team support
- Flexible return and exchange policy
Spirax Sarco Spirax Sarco CSF16/CSF16T stainless steel sterile air filters are horizontally mounted in-line high efficiency filters designed to remove impurity particles from gas systems. The filter housing is available in a choice of austenitic stainless steel 1.4301 for the CSF16 and 1.4404 for the CSF16T.
DN8 - DN80 outer cover is polished on the outer surface and naturally polished on the inner surface; DN100 - DN200 are naturally polished on both the outer and inner surfaces.
The outer housing consists of two halves in accordance with DIN 11851 for food industry connections, DN100 - DN200 the two parts are connected by bolts and nuts. Equipped with replaceable borosilicate cartridges of 0.01 μm, with a filtration rate of 99.99981 TP3T or more, and some pipe diameters are available in low-flow L-type and high-flow H-type cartridges. Products comply with the European Pressure Equipment Directive 97/23/EC, steel stamps are available on request, all materials comply with US FDA regulations, EN 10204 3.1 certificate is available (to be specified when ordering).
Sizes and pipe connections
- screw connection: BSP/NPT: ¼", ½", ¾", 1", 1¼", 1½", 2", 2½" and 3".
- flange connection::
- EN 1092 PN16: DN8, DN10, DN15, DN20, DN25, DN32, DN40, DN50, DN65 and DN80.
- EN 1092 PN10: DN100, DN150 and DN200.
- ASME 150: ¼", 3/8", ½", ¾", 1", 1¼", 1½", 2", 2½", 3", 4", 6" and 8".
Pressure/Temperature Limits
| Valve body design grade | PN16 |
|---|---|
| PMA Maximum Allowable Pressure | DN8 - DN65 (1/4" - 21/2"): 16 bar g; L-type DN80 (3"): 16 bar g; H-type: 12 bar g; DN100 - DN200: 10 bar g |
| TMA Maximum Allowable Temperature | DN8 - DN80: 178°C@8.5barg; DN100 - DN200: 150°C@8.1 bar g |
| Minimum permissible temperature | -20°C |
| PMO Maximum Working Pressure | DN8 - DN80: 8.5 bar g @ 178°C; DN100 - DN200: 8.1 bar g @ 150°C |
| TMO Maximum Operating Temperature | DN8 - DN80: 178°C@8.5 bar g; DN100 - DN200: 150°C@8.1 bar g |
| Minimum working temperature | 0°C |
| ΔPMX Maximum permissible differential pressure | 5 bar g |
| Design maximum cold hydraulic test pressure | DN8 - DN65 (1/4* to $2 \frac{1}{2}^{*}$): 27.5 bar g; L type DN80 (3"): 27.5 bar g; H type DN80 (3"): 20.6 bar g; DN100 - DN200: 18.3 bar g |
makings
| Item | Part | makings |
|---|---|---|
| 1 | Bottom cover of the outer casing | Stainless steel (CSF16: 1.4301; CSF16T: 1.4404) |
| 2 | canopy | Stainless steel (CSF16: 1.4301; CSF16T: 1.4404) |
| 3 | Cover sealing | DN8 - DN80: EPM; DN100 - DN200: stainless steel wound PTFE seals |
| 4 | Cover ring (DN8 - DN80) | Stainless steel 1.4301 |
| 5 | CSF16 - A cartridge | Cartridge material: milled silicate; Housing: 1.4301 |
| 6 | Cartridge seal (2 off) | Silicone VMQ |
| 7 | plug | Stainless steel (CSF16: 1.4301; CSF16T: 1.4404) |
| 8 | gaskets | PTFE |
| 9 | flangeless | Stainless steel 1.4541 |
| 10 | Bolts and nuts (DN100 - DN200) | Stainless steel A2 - 70 |
Displacement correction factor for gas pressure
| Compressed air pressure (bar g) | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| correction factor | 0.25 | 0.375 | 0.5 | 0.625 | 0.75 | 0.875 | 1.0 | 1.125 | 1.25 | 1.375 | 1.5 | 1.625 | 1.75 | 1.875 | 2.0 | 2.125 |
Selection table
The following flow rates are based on 7 barg of compressed air.
| caliber | DN8 | DN10 | DN15 | DN20 | DN25 | DN32 | DN40 | DN50L | DN50H | DN65 | DN80L | DN80H | DN100L | DN100H | DN150L | DN150H | DN200L | DN200H |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| corresponding size | 1/4" | 3/8 | 1/2" | 3/4 | 1" | 11/4" | 11/2" | 2 "L | 2 "H | 21/2 | 3 "L | 3 "H | 4 "L | 4 "H | 6 "L | 6 "H | 8''L | 8 "H |
| Maximum flow rate ($m^{3}/h$) | 60 | 90 | 120 | 180 | 270 | 360 | 480 | 720 | 1080 | 1440 | 1920 | 2880 | 4320 | 5760 | 7680 | 11520 | 15360 | 19200 |
Security information, installation and maintenance
For details, see the Installation and Maintenance Guide IM - P185 - 02 supplied with the product.
place an order
The following must be specified when ordering Spirax Sarco filters:
| sports event | element |
|---|---|
| Compressed air flow | $m^{3}/h$ |
| Compressed air pressure | bar |
| Allowable pressure drop | (Recommended maximum 0.07 bar) |
| Housing Material | 1.4301 or 1.4404 |
| caliber | DN or NPS (") |
| Pipe Connections | EN, ASME, BSP or NPT |
| Housing Seal / Cartridge Seal Material |
Note: For DN50 and DN80, high flow is indicated by "H" and low flow by "L". For 1.4404 enclosures, the suffix "T" must be added, e.g. CSF16T.
availability
CSF16 is provided in two parts:
- Outer housing bottom cover, top cover and outer housing seal.
- 2 sets of CSF16 - A silicate cartridges.
Note: Filter cartridges are used to remove impurities from the media and become saturated after a period of use. To minimize downtime, it is recommended to order a separate set of cartridges and covers as spare parts.
Ordering spare parts: Please order spare parts as described in the table above, indicating the type and size of the filter housing. Example: Seal set for a set of Spirax Sarco DN200H CSF16 filters.
